London Road Models

Hornblocks, Gears, Motors and Bearings


4mm Hornblocks, lost wax brass castings including either 1/8″ or 2mm bearings
Pack of Two (one axle) £6.00
Pack of Four (Two axles) £12.00
Pack of Four plus beam and pivot material. (Two axles) £12.75
Pack of Four plus beam material and blanking plates. (Two axles) £13.25
CSB/Spring adaptors for LRM hornblocks (etched) sufficient for an 0-6-0.
Click Here to Download Instructions as PDF;
£4.50
1/8″ Alignment Jigs – stainless steel (set of three) £5.00

4mm Hornblocks, Etched brass, Ex-Perseverance/Puffers including either 1/8″ or 2mm bearings
The sets include sufficient parts for four axles, one fixed and three in hornblocks, also includes rod and tube for Flexi-Chas compensation
Pack of etched hornblocks as above for 1/8th axles £9.00
Pack of etched hornblocks a above for 2mm axles. £9.00

Motors
Mashima 1015 skew wound flat can motor. £23.50
LRM1220 1220 coreless can motor. £21.00
LRM1227 1227 skew wound flat can motor. £24.00

Etched Motor Mounts for Mashima Motors
Note - With the demise of the Mashima range of motors, we intend keeping the present range in production for those who still have Mashima motors. We have sourced a small range of quality motors, which will use our gears, but, will need new mounts designed for them, watch this space!
GB4 Single stage motor mount, accepts all Mashima can motors (specify gear type and screw spacing) includes bearings. Ideal for use with small locos, with the motor ahead of and driving the rear axle, angled up into the firebox. This leaves the cab clear, and makes it easy to fit the body onto the chassis. Gears supplied separately (see below).

Click Here to Download Diagrams of etched motor mount and swing link outlines as a PDF"
£4.00

Swing – Link Extended Drive Motor Mounts for Mashima Motors
See above section for Note on Mashima Motors
Available in 38:1 or 50:1 ratios, Ultrascale type. Provides a variety of motor positions to locate the motor above the frames – especially useful when using larger motors with OO frame spacers. The motor mount diagram (see GB4 etched motor mounts below) is drawn to scale and can be used to identify how to fit the motor/motor mount into your model. Final drive gear fits standard 1/8″ axle. Includes gears, worm, bearings and intermediate shaft.
Please stipulate worm bore (1.5mm or 2.0mm ) for either type.
£25.00

Gears 1/8th” axle (please specify 1.5mm or 2.0mm shaft size).
38 to 1 “Ultrascale” type, with wormgear boss grubscrew fixing £8.50
50 to 1 “Ultrascale” type with wormgear boss grubscrew fixing £8.50

Bushes, Bearings, Etc.
Top hat bearings 1/8th axle. 4mm O/D. 3mm deep (12) £3.00
Top hat bearings 2mm axle. 4mm O/D. 3mm deep (12) £3.00
Top hat bearings 1/8th axle. 3.7mm O/D. 2mm deep (12) £3.00
Top hat bearings 2mm axle. 1/8th O/D. 2mm deep (10) £3.00
Top hat bearings 2mm axle. 2.7mm O/D.1.5mm deep (10) £3.00
Square bearings as cast hornblocks, 1/8th axle (6) £3.00
Square bearings as cast hornblocks, 2mm axle (6) £3.00
Square bearings as etched hornblocks 1/8th axle (6) £3.00
Square bearings as etched hornblocks 2mm axle (6) £3.00
Original Sharman flexi chas, round bearings 1/8th (10) £3.00
×
